Envelope Position

The envelope position of a named IV-spread category answers one question: when IV spreads in this category win, are they winning because the IV spreads themselves are special, or because almost any IV spread at the same stat-product rank would be winning those matchups?

That distinction matters when you’re deciding which IV spread to chase. A category that “rides above” the Anchor IVs band at its rank is doing something that the rank alone doesn’t buy you. A category that “straddles” the band is doing roughly what rank already predicts, and chasing a specific IV spread inside it isn’t worth extra effort.

What the Anchor IVs band is

Every dive has an Anchor IVs overlay on the scatter plot - a set of reference IVs (every IV spread that clears at least one named anchor - a breakpoint, bulkpoint, or CMP test - against the meta) that serve as the “what you’d naturally build” baseline. For every stat-product rank, there’s a set of anchor IVs at that rank and an average battle score for that set. Stacked across every rank, those averages trace out a band: a smooth curve of “what score do you get at rank N if you don’t go out of your way to pick a specific flavor?”

The envelope metric asks, for each named category (each row on the IV Flavor Guide, each composite card in the Per-matchup IV finder, each tier in Threshold Tiers): at matching stat-product rank, does this category’s score sit above, below, or on the band?

Tinkaton UL scatter plot showing named categories sitting
above, below, and across the Anchor IVs band. — Scatter plot from the Tinkaton UL dive. The triangle markers labelled **Anchor IVs** in the legend trace the reference band; the coloured category traces (Ampharos Atk, Annihilape Bulk, the Slayer cuts, Tinkaton Mirror Atk) sit above, below, and across it - that vertical position vs the band is exactly what the envelope metric measures. On this dive's current data every legend category classifies as a straddler; the clean riders are composite categories (e.g. CMP-First Slayer with 171+ bulk rides the top of the band, Anchors-First Slayer with Annihilape Bulk rides the bottom), whose tags appear on their cards in the Per-matchup IV finder rather than as scatter traces.

Why the Anchor IVs markers change color across the rank axis. Each triangle’s inner fill matches what that IV spread would look like in the base scatter underneath. So in the default Color: Threshold tiers mode, anchor IVs that clear a named tier take that tier’s color; untiered anchor IVs take a Viridis-by-score gradient. Switch the Color dropdown to a stat axis like “HP” or “Attack” and every anchor fill flips to a fixed gold - the per-tier mapping doesn’t apply outside threshold mode. Switch the Anchors dropdown to Outline and the fill drops out entirely, leaving a cyan ring per anchor IV so the band reads as an envelope edge.

The four shapes

Each category carries a shape label, derived from two numbers:

mean_delta - the signed average, in battle-score units, of how far this category’s members sit from the anchor band at their matching ranks. Positive means above the band; negative means below.
spread - the stdev of the per-member deltas. A small spread means every member sits at roughly the same distance from the band; a large spread means some members beat the band and others fall below it.

The classifier splits on the ratio |mean_delta| / spread. If the mean is at least 1.5x the stdev, the category is a rider (members consistently on one side of the band). Otherwise it’s a band-crosser (members scatter across the band; the sign of the mean tells you which way the scatter tilts).

That gives four named shapes. The first, second, and fourth each have a labeled trace on the screenshot above; the third (depressed-band-crosser) appears in Tinkaton UL only as single-matchup cohorts that don’t get dedicated traces.

Rides top of anchor band (rider-top) - members consistently above the band. These earn their spot on top of the score distribution not by rank alone but by some property of the IV cut itself. For example, see the Steelix (Shadow) Slayer trace in the screenshot above - a tight cluster hugging the upper edge of the grey Anchor IVs band.
Straddles band (net +) (elevated-band-crosser) - mixed, but averages above the band. The cut helps on average; chasing a specific member IV isn’t strictly required. For example, the Ampharos Atk trace above - clearly elevated overall, but visibly spread across the band rather than hugging the edge.
Straddles band (net -) (depressed-band-crosser) - mixed, averages below. The cut hurts on average; clearing the tier in question may not be worth the trade.
Rides bottom of anchor band (rider-bottom) - members consistently below. Category to avoid. For example, the Annihilape Bulk trace above - a tight cluster hugging the bottom edge of the anchor band.

A fifth label, sparse, fires when the category has too few members or too few anchors for the metric to be informative. The dive renderer skips sparse categories entirely rather than showing a misleading tag.

Where the tag shows up on a dive

Two places:

Per-category, on the composite (slayer + tier) cards in the Per-matchup IV finder (the section formerly called Notable IVs). The tag line reads like:

Envelope: Straddles band (net -) (avg -0.3, spread 0.9)

Hover the tag for a full tooltip: “Avg battle-score delta vs the anchor-IV band at matching stat-product rank. -0.3 average, spread 0.9 (stdev) across 7 members and 2617 anchor IVs.”

At the top of the page in the Overview / Meta Role narrative, as a single sentence counting how many categories land in each bucket. On the reference Oinkologne (Female) Great League dive, it reads:

Envelope shape. 26 of 208 named categories ride above the anchor band …; 1 ride below …; 181 straddle.

How to read the numbers on a tag

The two numbers in parentheses (avg X, spread Y) tell you what you’re looking at:

avg close to 0 means the category is sitting roughly on the band. Score-wise, members are interchangeable with what a typical rank-matched anchor IV spread would produce. Skip.
avg large (positive or negative), spread small means everyone in the category is reliably off the band in the same direction. A +2.8 avg, 0.4 spread rider tag is saying: “every member beats the band by 2-3 points; zero of them are edge-cases.”
avg moderate, spread large means the category has mixed wins and losses across its members. A +0.5 avg, 1.4 spread tag says: “on average members beat the band a little, but picking the wrong specific IV inside this category can put you below it.” Here the specific IV matters - chasing a named member of the category is the only way to collect the positive tail.

A rule of thumb: spread under ~0.5 means the members behave as a tight cluster; over ~1.5 means they scatter. mean_delta in the single digits is typical (battle scores live in the hundreds but delta-vs-band is usually small); a mean_delta above 3 is a strong signal in either direction.

Worked example: Oinkologne (Female) in Great League

Looking at the envelope count on the reference dive: 26 categories ride above, 1 ride below, and 181 straddle the band (out of 208 classified).

That distribution is typical for a mid-role species: the overwhelming majority of categories straddle, which means the rank-matched anchor band is a strong predictor of outcome. The handful of riders are the interesting ones - either ship-quality picks (rider-top) or explicit traps (rider-bottom) where the mean is persistently off the band.

On the Per-matchup IV finder’s composite cards you can see the per-category tags: the composite Slayer-plus-Bulk cards that cover a defensive trade carry Straddles band (net -) tags, which matches the intuition that trading def-sacrifice for atk gains is a wash on average.

How to use this when picking an IV

Work the envelope tag together with the category’s member count (how many IV spreads qualify) and the cutoffs themselves:

Rider-top + small member count = the combination to chase. Few IV spreads qualify, but every one that does beats the band. This is the “rare but worth the trade” IV spread.
Rider-top + large member count = free lunch. Most IV spreads already sit here; you don’t need to chase anything specific.
Straddles band + small member count = low confidence. The category narrows the IV space but the mean effect is flat. Either rank or a specific-IV chase is better than chasing this category.
Rider-bottom at any member count = avoid. Members are persistently below band.

The Paste-box CSV overlay on the scatter plot makes this concrete: paste your own IV spreads into the plot, switch to the category whose tag you like, and see instantly which of your catchable IV spreads land inside a rider-top band vs a straddle.

Where to go next

IV Flavor Guide - the teal narrative zone that names each flavor and gives you the per-flavor trade-off list. Envelope shapes and flavor cards describe the same named categories; the two are meant to be read together.
Threshold Tiers - tier categories are classified by the same envelope metric (they feed the envelope-shape count in the Overview). If a tier’s category straddles the band, the tier’s cutoff is mechanically sound but doesn’t move the score needle on average.
Deep-Dive Scatter - the Anchor IVs band is an overlay on the scatter plot; the scatter guide covers the Filled / Outline dropdown and how to read the overlay against named category traces.
How This Works - if you want the short version of how the underlying simulation and scatter plot are built.
